TwoBody.jl: a Julia package for two-body problems
Install
Run the following code on the REPL or Jupyter Notebook to install this package.
import Pkg; Pkg.add(url="https://github.com/ohno/TwoBody.jl.git")
Usage
Run the following code before each use.
using TwoBody
Define the Hamiltoninan. This is an example for the non-relativistic Hamiltonian of hydrogen atom in atomic units:
\[\hat{H} = - \frac{1}{2} \nabla^2 - \frac{1}{r}\]
H = Hamiltonian(
NonRelativisticKinetic(ℏ = 1 , m = 1),
CoulombPotential(coefficient = -1),
)
The usage depends on the method. Define the basis set for the Rayleigh–Ritz Method:
\[\begin{aligned} \phi_1(r) &= \exp(-13.00773 ~r^2), \\ \phi_2(r) &= \exp(-1.962079 ~r^2), \\ \phi_3(r) &= \exp(-0.444529 ~r^2), \\ \phi_4(r) &= \exp(-0.1219492 ~r^2). \end{aligned}\]
BS = BasisSet(
SimpleGaussianBasis(13.00773),
SimpleGaussianBasis(1.962079),
SimpleGaussianBasis(0.444529),
SimpleGaussianBasis(0.1219492),
)
You should find
\[E_{n=1} = -0.499278~E_\mathrm{h},\]
which is amazingly good for only four basis functions according to Thijssen(2007). The exact ground-state energy is $-0.5~E_\mathrm{h}$.
julia> solve(H, BS)
# method Rayleigh–Ritz method with SimpleGaussianBasis J. Thijssen, Computational Physics 2nd Edition (2013) https://doi.org/10.1017/CBO9781139171397 # basis function φ₁(r) = TwoBody.φ(SimpleGaussianBasis(a=13.00773), r) φ₂(r) = TwoBody.φ(SimpleGaussianBasis(a=1.962079), r) φ₃(r) = TwoBody.φ(SimpleGaussianBasis(a=0.444529), r) φ₄(r) = TwoBody.φ(SimpleGaussianBasis(a=0.1219492), r) # eigenfunction ψ₁(r) = + 0.096102φ₁(r) + 0.163017φ₂(r) + 0.185587φ₃(r) + 0.073701φ₄(r) ψ₂(r) = + 0.119454φ₁(r) + 0.081329φ₂(r) + 0.496216φ₃(r) - 0.205916φ₄(r) ψ₃(r) = - 0.010362φ₁(r) + 1.744891φ₂(r) - 0.629196φ₃(r) + 0.097774φ₄(r) ψ₄(r) = - 6.155100φ₁(r) + 1.240202φ₂(r) - 0.226412φ₃(r) + 0.030780φ₄(r) # eigenvalue E₁ = -0.4992784056674876 E₂ = 0.11321392045798988 E₃ = 2.592299571959808 E₄ = 21.144365190122507 # others n norm, <ψₙ|ψₙ> = cₙ' * S * cₙ 1 1.0 2 1.0000000000000004 3 1.0 4 0.9999999999999988 n error check, |<ψₙ|H|ψₙ> - E| = |cₙ' * H * cₙ - E| = 0 1 1.8318679906315083e-15 2 3.4833247397614286e-15 3 3.552713678800501e-15 4 1.7763568394002505e-14 n expectation value of NonRelativisticKinetic(ħ=1, m=1) 1 0.4992783686700055 2 0.8428088332141157 3 4.432656608731447 4 26.465623640332108 n expectation value of CoulombPotential(coefficient=-1) 1 -0.9985567743374912 2 -0.7295949127561296 3 -1.8403570367716342 4 -5.321258450209621 (hamiltonian = Hamiltonian(NonRelativisticKinetic(ħ=1, m=1), CoulombPotential(coefficient=-1)), perturbation = Hamiltonian(), basisset = BasisSet(SimpleGaussianBasis(a=13.00773), SimpleGaussianBasis(a=1.962079), SimpleGaussianBasis(a=0.444529), SimpleGaussianBasis(a=0.1219492)), nₘₐₓ = 4, H = [0.5772684658780091 0.072002466903411 -0.32154049871511875 -0.43612626272313476; 0.072002466903411 0.5070499286923358 -0.9891848263978418 -2.377419924763058; -0.32154049871511875 -0.9891848263978418 -2.6380824346106566 -7.342216931051755; -0.43612626272313476 -2.377419924763058 -7.342216931051755 -17.30516271277891], S = [0.041964064408426524 0.0961391814715395 0.11285790355607861 0.11704251263182287; 0.0961391814715395 0.7163167080668228 1.4914777365294443 1.8508423236885296; 0.11285790355607861 1.4914777365294443 6.642471010530628 13.060205391889545; 0.11704251263182287 1.8508423236885296 13.060205391889545 46.22866820431064], E = [-0.4992784056674876, 0.11321392045798988, 2.592299571959808, 21.144365190122507], C = [0.09610151618612488 0.1194538057449333 -0.010362061881687392 -6.155100006789123; 0.16301716963905885 0.08132945379475047 1.7448913023470436 1.2402020851506472; 0.18558698714513683 0.49621626366832666 -0.6291955141735303 -0.22641160819529882; 0.07370076069275631 -0.20591550816511817 0.09777447415099819 0.030779842546714373], φ = TwoBody.var"#42#49"{Int64, BasisSet}[TwoBody.var"#42#49"{Int64, BasisSet}(1, BasisSet(SimpleGaussianBasis(a=13.00773), SimpleGaussianBasis(a=1.962079), SimpleGaussianBasis(a=0.444529), SimpleGaussianBasis(a=0.1219492))), TwoBody.var"#42#49"{Int64, BasisSet}(2, BasisSet(SimpleGaussianBasis(a=13.00773), SimpleGaussianBasis(a=1.962079), SimpleGaussianBasis(a=0.444529), SimpleGaussianBasis(a=0.1219492))), TwoBody.var"#42#49"{Int64, BasisSet}(3, BasisSet(SimpleGaussianBasis(a=13.00773), SimpleGaussianBasis(a=1.962079), SimpleGaussianBasis(a=0.444529), SimpleGaussianBasis(a=0.1219492))), TwoBody.var"#42#49"{Int64, BasisSet}(4, BasisSet(SimpleGaussianBasis(a=13.00773), SimpleGaussianBasis(a=1.962079), SimpleGaussianBasis(a=0.444529), SimpleGaussianBasis(a=0.1219492)))], ψ = TwoBody.var"#44#51"{Int64, BasisSet, Matrix{Float64}, Int64}[TwoBody.var"#44#51"{Int64, BasisSet, Matrix{Float64}, Int64}(1, BasisSet(SimpleGaussianBasis(a=13.00773), SimpleGaussianBasis(a=1.962079), SimpleGaussianBasis(a=0.444529), SimpleGaussianBasis(a=0.1219492)), [0.09610151618612488 0.1194538057449333 -0.010362061881687392 -6.155100006789123; 0.16301716963905885 0.08132945379475047 1.7448913023470436 1.2402020851506472; 0.18558698714513683 0.49621626366832666 -0.6291955141735303 -0.22641160819529882; 0.07370076069275631 -0.20591550816511817 0.09777447415099819 0.030779842546714373], 4), TwoBody.var"#44#51"{Int64, BasisSet, Matrix{Float64}, Int64}(2, BasisSet(SimpleGaussianBasis(a=13.00773), SimpleGaussianBasis(a=1.962079), SimpleGaussianBasis(a=0.444529), SimpleGaussianBasis(a=0.1219492)), [0.09610151618612488 0.1194538057449333 -0.010362061881687392 -6.155100006789123; 0.16301716963905885 0.08132945379475047 1.7448913023470436 1.2402020851506472; 0.18558698714513683 0.49621626366832666 -0.6291955141735303 -0.22641160819529882; 0.07370076069275631 -0.20591550816511817 0.09777447415099819 0.030779842546714373], 4), TwoBody.var"#44#51"{Int64, BasisSet, Matrix{Float64}, Int64}(3, BasisSet(SimpleGaussianBasis(a=13.00773), SimpleGaussianBasis(a=1.962079), SimpleGaussianBasis(a=0.444529), SimpleGaussianBasis(a=0.1219492)), [0.09610151618612488 0.1194538057449333 -0.010362061881687392 -6.155100006789123; 0.16301716963905885 0.08132945379475047 1.7448913023470436 1.2402020851506472; 0.18558698714513683 0.49621626366832666 -0.6291955141735303 -0.22641160819529882; 0.07370076069275631 -0.20591550816511817 0.09777447415099819 0.030779842546714373], 4), TwoBody.var"#44#51"{Int64, BasisSet, Matrix{Float64}, Int64}(4, BasisSet(SimpleGaussianBasis(a=13.00773), SimpleGaussianBasis(a=1.962079), SimpleGaussianBasis(a=0.444529), SimpleGaussianBasis(a=0.1219492)), [0.09610151618612488 0.1194538057449333 -0.010362061881687392 -6.155100006789123; 0.16301716963905885 0.08132945379475047 1.7448913023470436 1.2402020851506472; 0.18558698714513683 0.49621626366832666 -0.6291955141735303 -0.22641160819529882; 0.07370076069275631 -0.20591550816511817 0.09777447415099819 0.030779842546714373], 4)])
The wave function is also good. However, the Gaussian basis does not satisfy the Kato’s cusp condition.
# solve
res = solve(H, BS, info=0)
# benchmark
import Antique
HA = Antique.HydrogenAtom(Z=1, Eₕ=1.0, a₀=1.0, mₑ=1.0, ℏ=1.0)
# plot
using CairoMakie
fig = Figure(size=(420,300), fontsize=11.5, backgroundcolor=:transparent)
axis = Axis(fig[1,1], xlabel=L"$r / a_0$", ylabel=L"$\psi(r) / a_0^{-3/2}$", ylabelsize=16.5, xlabelsize=16.5, limits=(0,4,0,1.1/sqrt(π)))
lines!(axis, 0..5, r -> abs(res.ψ[1](r)), label="TwoBody.jl")
lines!(axis, 0..5, r -> abs(Antique.ψ(HA,r,0,0)), linestyle=:dash, color=:black, label="Antique.jl")
axislegend(axis, position=:rt, framevisible=false)
fig

API reference
TwoBody.Basis
TwoBody.BasisSet
TwoBody.ConstantPotential
TwoBody.ContractedBasis
TwoBody.CoulombPotential
TwoBody.DeltaPotential
TwoBody.ExponentialPotential
TwoBody.FiniteDifferenceMethod
TwoBody.FunctionPotential
TwoBody.GaussianBasis
TwoBody.GaussianPotential
TwoBody.GeometricBasisSet
TwoBody.Hamiltonian
TwoBody.KineticTerm
TwoBody.Laplacian
TwoBody.LinearPotential
TwoBody.NonRelativisticKinetic
TwoBody.Operator
TwoBody.PotentialTerm
TwoBody.PowerLawPotential
TwoBody.PrimitiveBasis
TwoBody.RelativisticCorrection
TwoBody.RelativisticKinetic
TwoBody.RestEnergy
TwoBody.SimpleGaussianBasis
TwoBody.UniformGridPotential
TwoBody.YukawaPotential
TwoBody.element
TwoBody.element
TwoBody.element
TwoBody.element
TwoBody.element
TwoBody.element
TwoBody.element
TwoBody.element
TwoBody.element
TwoBody.element
TwoBody.geometric
TwoBody.matrix
TwoBody.matrix
TwoBody.matrix
TwoBody.matrix
TwoBody.matrix
TwoBody.matrix
TwoBody.optimize
TwoBody.optimize
TwoBody.optimize
TwoBody.solve
TwoBody.solve
TwoBody.solve
TwoBody.solve
TwoBody.solve
